Descripción
Especificaciones técnicas: Ficha-Tecnica-DVR-HIKVISION_DS-7200HGHI-F1_V3.4.89
Grabación
- Compresión de vídeo: H.264+ / H.264
- Encoding resolution: When 1080P Lite Mode Not Enabled: 720P / WD1 / 4CIF / VGA / CIF, When 1080P Lite Mode Enabled: 1080P Lite / 720P / WD1 / 4CIF / VGA / CIF.
- Frame rate: Main Stream: When 1080P Lite Mode Not Enabled: For 720P Stream Access: 720P / WD1 / 4CIF / VGA / CIF@25Fps (P) / 30Fps (N), When 1080P Lite Mode Enabled: 1080P Lite / 720P / WD1 / 4CIF / VGA / CIF@25Fps (P) / 30Fps (N), Sub-stream: 2CIF@6Fps; CIF / QVGA / QCIF@ 25Fps (P) / 30Fps (N).
- Vídeo bitrate: 32Kbps to 4Mbps
- Dual stream: Support
- Stream type: Video, Video & Audio.
- Audio compression: G.711U
- Audio bit rate: 64Kbps
Vídeo y Audio
- Entrada de vídeo: IP1-Ch (Up to 5-ch) Up to 960P Resolution Support H.264+ / H.264 IP Cameras
- Analog video input: 4-Ch BNC Interface (1.0Vp-p, 75 Ω), Supporting Coaxitron Connection
- Turbo HD input: 1080P 25, 1080P 30, 720P 25, 720P 30
- AHD input: 1080P 25, 1080P 30, 720P 25, 720P 30
- HDCVI input: 1080P 25, 1080P 30, 720P 25, 720P 30
- CVBS input: Support
- Entrada de audio: 1-Ch, RCA (2.0Vp-p, 1 KΩ)
- Salida de audio: 1-Ch, RCA (Linear, 1 KΩ)
- Audio bidireccional: Reuse the first Audio Input
- Reproducción síncrona: 4-Ch
- VGA/HDMI output: 1-Ch, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
Red
- Conexiones remotas: 32
- Network protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
- Interfaz de Red: 1, RJ45 10M/100M Self-adaptive Ethernet interface.
Auxiliary Interface
- SATA: 1 SATA interface
- Capacidad: Up to 6TB capacity for each disk.
- Alarm In/Out: N/A
- Interfaz USB: Rear Panel: 2 × USB 2.0
General
- Fuente de alimentación: 12V DC
- Temperatura de trabajo: -10°C to 55°C (14°F to 131°F)
- Humedad de trabajo: 10% to 90%
- Weights (Without HDD): ≤ 1Kg (2.2Lb)
- Consumption (Without HDD): ≤ 8W
- Dimensiones (W × D × H): 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
